Nor1545 Noise Monitoring Terminal

Nor1545 outdoor noise monitoring terminal with Class 1 sound level meter, weatherproof enclosure, 4G connectivity, and NorCloud integration for permanent environmental monitoring.

Overview

The Nor1545 noise monitoring terminal is a purpose-built outdoor noise monitoring system designed for permanent, unattended deployment in the most demanding environmental conditions. Built around the PTB type-approved Nor145 Class 1 sound level meter, the Nor1545 delivers legally compliant noise data with the reliability required for regulatory monitoring programs, infrastructure projects, and ind…

Key Features

  • PTB type-approved Class 1 sound level meter for regulatory compliance
  • IP65/66 weatherproof enclosure for harsh outdoor environments
  • 4G LTE and WLAN connectivity for real-time remote monitoring
  • NorCloud integration for multi-site fleet management and alerts
  • Solar power option for off-grid installations
  • Continuous and trigger-based audio recording for source identification
  • Wide operating temperature range -25 degrees C to +55 degrees C
  • Automated email/SMS alarms for threshold exceedances

Applications

  • Permanent airport noise monitoring per ICAO guidelines
  • Road and railway traffic noise monitoring per EU directive 2002/49/EC
  • Construction site noise monitoring for permit compliance
  • Industrial facility perimeter noise monitoring
  • Wind farm noise monitoring and complaints management
  • Event venue noise monitoring for license compliance

Technical Specifications

  • Model: Nor1545
  • Sound Level Meter: Class 1 per IEC 61672-1
  • Type Approvals: PTB approved
  • Frequency Range: 10 Hz – 20 kHz
  • Dynamic Range: > 120 dB
  • Measurement Range: 25 dB(A) to 140 dB(A)
  • Octave Filters: 1/1 and 1/3 octave, real-time
  • Audio Recording: Continuous or trigger-based
  • Enclosure: IP65/IP66 weatherproof housing
  • Connectivity: 4G LTE, WLAN, Ethernet
  • Power Options: Mains, solar panel, battery backup
  • Operating Temperature: -25°C to +55°C

Frequently Asked Questions

  • Is the Nor1545 suitable for permanent outdoor installation?
    Yes. The IP65/66-rated enclosure is designed for long-term unattended outdoor deployment in temperatures from -25 degrees C to +55 degrees C. This makes it fully capable of withstanding the extreme summer heat in Saudi Arabia, the UAE, and other GCC countries.
  • Can I access monitoring data remotely?
    Yes. Built-in 4G LTE and WLAN enable secure remote access through the NorCloud platform. You can view live data, configure alarm thresholds, retrieve historical measurements, and manage multiple terminals from anywhere with an internet connection.
  • What power options are available?
    The Nor1545 supports mains power, battery backup for uninterrupted operation during power outages, and solar power for remote installations without grid access. The solar option is particularly valuable for monitoring sites in remote desert locations across the GCC.

Application Guide

The Nor1545 Noise Monitoring Terminal belongs to the Norsonic Noise Monitoring range. See the Noise Monitoring application guide for system configuration, compatible accessories, and applicable measurement standards.

Related Norsonic Products

Why Norsonic?

  • Manufactured in Norway — decades of acoustic measurement heritage; all instruments designed and built in Norsonic AS, Lierskogen, Norway
  • IEC 61672 Class 1 — highest accuracy class for professional and regulatory acoustic measurement
  • International type approvals — PTB (Germany) and LNE (France); accepted by environmental authorities across the region
  • 3-year manufacturer warranty — covers parts and labour; Norsonic Asia authorized service center support throughout the region
  • Open data formats — .nox files work with NorReview and can be exported to CSV, Excel, and third-party analysis software

Calibration and Compliance

  • All Norsonic instruments require periodic IEC 61672-3 calibration — Norsonic Asia provides factory-authorized calibration services with full DANAK-traceable certificates
  • Calibration interval: 1 year for ISO 17025 accredited laboratories; 2 years for field instruments in non-accredited applications
  • Field calibration check: use an IEC 60942 Class 1 sound calibrator (94 dB or 114 dB) before and after each measurement session
  • Loaner instruments available during calibration to minimize project downtime — contact Norsonic Asia for loaner availability

Availability & Regional Support

Available from Norsonic Asia — the factory-authorized distributor for ASEAN, GCC, and South Asia. Instrument supply includes 3-year manufacturer warranty, factory-authorized calibration services, operator training, and after-sales technical support.

  • Typical lead time: 3–6 weeks from order confirmation (ex-factory Norway)
  • Countries served: Singapore, Malaysia, Thailand, Vietnam, Philippines, Indonesia, UAE, Saudi Arabia, Qatar, Kuwait, India, Bangladesh, Sri Lanka, and more
  • Technical support: English and Arabic; response within 1 business day
